参数说明：
功率：15W(3IK15GN-C+3GN15K,3IK15RGN-C+3GN30K)
更多功率：6W 15W 25W 40W 60W 90W 120W 140W 150W 160W 180W 200W 250W 300W 400W
电压：单相110V/220V
电流：0.1A至3.5A频率：50Hz/60Hz
转速：1至2800RPM可减速可调速电机

减速比：1:3至1:600
转向:CW(正转)/CCW(反转)绝缘等级:B级
耐温:-10至130℃工作制:S1S2S3
防护等级:IP44（可定制IP55）噪音:50dB以下
安装方式：立式/卧式功能：无级调速，电磁刹车，正反转
电机材料及特点：
优质纯铜线圈
40Cr合金钢齿轮高温氮化加硬
407硅钢片，铁损更低，磁通量更大
ADC12全铝制电机外壳
德国原装进口低温油脂
全铝制散热风扇
散热条使用定子线圈，电机工作时产生的热量更易散发
高速冲床定子
转子使用金属镶件加入模具，注入BMC材料加热至180℃高温成型
电机优点
超强扭矩   超低噪音   超长寿命  高可靠性
启动平稳   安装方便   节省空间  免维护
售后服务：
7天包退15天包换2年包修5年维护

注意事项：
1.在电机出轴上安装连轴器或皮带轮等传动机构时，不可直接在出轴上以工具敲击安装。
2.与其他机器连接时，请先确认好旋转方向。
3.为避免安全隐患，请接地线使用。
4.带接线盒电机，请不要在接线盒盖打开的状态下运转电机。
5.安装接线时，请先确认好电压务必控制在额定范围内，以免因使用错误电压而导致电机线圈烧坏及触电。
6.请勿在通电状态下进行移动，安装，接线和检查作业。请切断电源后再进行作业，否则可能引起触电。
电机型号：

3IK15A-C	3RK15A-C	3IK15GN-C	3RK15GN-C
3IK15RA-C	3RK15RA-C	3IK15RGN-C	3RK15RGN-C

减速机型号：

3GN3K	3GN5K	3GN7.5K	3GN9K	3GN10K	3GN12.5K	3GN15K	3GN18K
3GN20K	3GN25K	3GN30K	3GN36K	3GN40K	3GN50K	3GN60K	3GN75K
3GN90K	3GN100K	3GN120K	3GN150K	3GN180K	3GN6K	3GN250K	3GN300K





应用范围：
输送带，流水线，磁性分离器,传送带,巴氏灭菌机,包装印刷机,玻璃反应釜,剥皮机,剥线机,贴片机,口罩机，防护服设备等自动化


6W光轴电机型号汇总
3IK15A-A，3IK15A-C，3IK15A-S，3IK15A-S3，3IK15A-D，3IK15A-T，3IK15A-T3，3IK15RA-C，3IK15A-CM，3IK15RA-CM，3IK15GN-A，3IK15GN-C，3IK15RGN-C，3IK15GN-CM，3IK15RGN-CM，3RK15GN-C，3RK15RN-C，3RK15GN-A，3RK15RN-A，3IK15GN-S
3IK15GN-S3，3IK15GN-Y，3IK15GN-SM，3IK15GN-S3M，3IK15GN-YM，
6W减速电机型号汇总：
3IK15GN-C+3GN3K，3IK15GN-C+3GN5K，3IK15GN-C+3GN7.5K，3IK15GN-C+3GN9K，3IK15GN-C+3GN10K，3IK15GN-C+3GN12.5K，3IK15GN-C+3GN15K，3IK15GN-C+3GN18K，3IK15GN-C+3GN20K，3IK15GN-C+3GN25K，3IK15GN-C+3GN30K，3IK15GN-C+3GN36K，3IK15GN-C+3GN40K，3IK15GN-C+3GN50K，3IK15GN-C+3GN60K，3IK15GN-C+3GN75K，3IK15GN-C+3GN90K，3IK15GN-C+3GN100K，3IK15GN-C+3GN120K，3IK15GN-C+3GN150K，3IK15GN-C+3GN180K，3IK15GN-C+3GN200K，3IK15GN-C+3GN250K
6W调速电机型号汇总：
3IK15RGN-C+3GN3K，3IK15RGN-C+3GN5K，3IK15RGN-C+3GN7.5K，3IK15RGN-C+3GN9K，3IK15RGN-C+3GN10K，3IK15RGN-C+3GN12.5K，3IK15RGN-C+3GN15K，3IK15RGN-C+3GN18K，3IK15RGN-C+3GN20K，3IK15RGN-C+3GN25K，3IK15RGN-C+3GN30K，3IK15RGN-C+3GN36K，3IK15RGN-C+3GN40K，3IK15RGN-C+3GN50K，3IK15RGN-C+3GN60K，3IK15RGN-C+3GN75K，3IK15RGN-C+3GN90K，3IK15RGN-C+3GN100K，3IK15RGN-C+3GN120K，3IK15RGN-C+3GN150K，3IK15RGN-C+3GN180K，3IK15RGN-C+3GN200K，3IK15GN-C+3GN250K
6W阻尼定速电机汇总：
3RK15GN-C+3GN3K，3RK15GN-C+3GN5K，3RK15GN-C+3GN7.5K，3RK15GN-C+3GN9K，3RK15GN-C+3GN10K，3RK15GN-C+3GN12.5K，3RK15GN-C+3GN15K，3RK15GN-C+3GN18K，3RK15GN-C+3GN20K，3RK15GN-C+3GN25K，3RK15GN-C+3GN30K，3RK15GN-C+3GN36K，3RK15GN-C+3GN40K，3RK15GN-C+3GN50K，3RK15GN-C+3GN60K，3RK15GN-C+3GN75K，3RK15GN-C+3GN90K，3RK15GN-C+3GN100K，3RK15GN-C+3GN120K，3RK15GN-C+3GN150K，3RK15GN-C+3GN180K，3RK15GN-C+3GN200K，3RK15GN-C+3GN250K
6W阻尼调速电机型号汇总：
3RK15RGN-C+3GN3K，3RK15RGN-C+3GN5K，3RK15RGN-C+3GN7.5K，3RK15RGN-C+3GN9K，3RK15RGN-C+3GN10K，3RK15RGN-C+3GN12.5K，3RK15RGN-C+3GN15K，3RK15RGN-C+3GN18K，3RK15RGN-C+3GN20K，3RK15RGN-C+3GN25K，3RK15RGN-C+3GN30K，3RK15RGN-C+3GN36K，3RK15RGN-C+3GN40K，3RK15RGN-C+3GN50K，3RK15RGN-C+3GN60K，3RK15RGN-C+3GN75K，3RK15RGN-C+3GN90K，3RK15RGN-C+3GN100K，3RK15RGN-C+3GN120K，3RK15RGN-C+3GN150K，3RK15RGN-C+3GN180K，3RK15RGN-C+3GN200K，3RK15GN-C+3GN250K
6W定速刹车型号汇总：
3IK15GN-CM+3GN3K，3IK15GN-CM+3GN5K，3IK15GN-CM+3GN7.5K，3IK15GN-CM+3GN9K，3IK15GN-CM+3GN10K，3IK15GN-CM+3GN12.5K，3IK15GN-CM+3GN15K，3IK15GN-CM+3GN18K，3IK15GN-CM+3GN20K，3IK15GN-CM+3GN25K，3IK15GN-CM+3GN30K，3IK15GN-CM+3GN36K，3IK15GN-CM+3GN40K，3IK15GN-CM+3GN50K，3IK15GN-CM+3GN60K，3IK15GN-CM+3GN75K，3IK15GN-CM+3GN90K，3IK15GN-CM+3GN100K，3IK15GN-CM+3GN120K，3IK15GN-CM+3GN150K，3IK15GN-CM+3GN180K，3IK15GN-CM+3GN200K，3IK15GN-CM+3GN250K，
6W调速刹车型号汇总：
3IK15RGN-CM+3GN3K，3IK15RGN-CM+3GN5K，3IK15RGN-CM+3GN7.5K，3IK15RGN-CM+3GN9K，3IK15RGN-CM+3GN10K，3IK15RGN-CM+3GN12.5K，3IK15RGN-CM+3GN15K，3IK15RGN-CM+3GN18K，3IK15RGN-CM+3GN20K，3IK15RGN-CM+3GN25K，3IK15RGN-CM+3GN30K，3IK15RGN-CM+3GN36K，3IK15RGN-CM+3GN40K，3IK15RGN-CM+3GN50K，3IK15RGN-CM+3GN60K，3IK15RGN-CM+3GN75K，3IK15RGN-CM+3GN90K，3IK15RGN-CM+3GN100K，3IK15RGN-CM+3GN120K，3IK15RGN-CM+3GN150K，3IK15RGN-CM+3GN180K，3IK15RGN-CM+3GN200K，3IK15RGN-CM+3GN250K
6W三相220V减速电机型号汇总：
3IK15GN-S+3GN3K，3IK15GN-S+3GN5K，3IK15GN-S+3GN7.5K，3IK15GN-S+3GN9K，3IK15GN-S+3GN10K，3IK15GN-S+3GN12.5K，3IK15GN-S+3GN15K，3IK15GN-S+3GN18K，3IK15GN-S+3GN20K，3IK15GN-S+3GN25K，3IK15GN-S+3GN30K，3IK15GN-S+3GN36K，3IK15GN-S+3GN40K，3IK15GN-S+3GN50K，3IK15GN-S+3GN60K，3IK15GN-S+3GN75K，3IK15GN-S+3GN90K，3IK15GN-S+3GN100K，3IK15GN-S+3GN120K，3IK15GN-S+3GN150K，3IK15GN-S+3GN180K，3IK15GN-S+3GN200K，3IK15GN-S+3GN250K
6W三相380V减速电机型号汇总：
3IK15GN-S3+3GN3K，3IK15GN-S3+3GN5K，3IK15GN-S3+3GN7.5K，3IK15GN-S3+3GN9K，3IK15GN-S3+3GN10K，3IK15GN-S3+3GN12.5K，3IK15GN-S3+3GN15K，3IK15GN-S3+3GN18K，3IK15GN-S3+3GN20K，3IK15GN-S3+3GN25K，3IK15GN-S3+3GN30K，3IK15GN-S3+3GN36K，3IK15GN-S3+3GN40K，3IK15GN-S3+3GN50K，3IK15GN-S3+3GN60K，3IK15GN-S3+3GN75K，3IK15GN-S3+3GN90K，3IK15GN-S3+3GN100K，3IK15GN-S3+3GN120K，3IK15GN-S3+3GN150K，3IK15GN-S3+3GN180K，3IK15GN-S3+3GN200K，3IK15GN-S3+3GN250K
6W三相通用220V/380V减速电机型号汇总：
3IK15GN-Y+3GN3K，3IK15GN-Y+3GN5K，3IK15GN-Y+3GN7.5K，3IK15GN-Y+3GN9K，3IK15GN-Y+3GN10K，3IK15GN-Y+3GN12.5K，3IK15GN-Y+3GN15K，3IK15GN-Y+3GN18K，3IK15GN-Y+3GN20K，3IK15GN-Y+3GN25K，3IK15GN-Y+3GN30K，3IK15GN-Y+3GN36K，3IK15GN-Y+3GN40K，3IK15GN-Y+3GN50K，3IK15GN-Y+3GN60K，3IK15GN-Y+3GN75K，3IK15GN-Y+3GN90K，3IK15GN-Y+3GN100K，3IK15GN-Y+3GN120K，3IK15GN-Y+3GN150K，3IK15GN-Y+3GN180K，3IK15GN-Y+3GN200K，3IK15GN-Y+3GN250K
6W三相通用220V/380V减速电机型号汇总：
3IK15GN-S/S3+3GN3K，3IK15GN-S/S3+3GN5K，3IK15GN-S/S3+3GN7.5K，3IK15GN-S/S3+3GN9K，3IK15GN-S/S3+3GN10K，3IK15GN-S/S3+3GN12.5K，3IK15GN-S/S3+3GN15K，3IK15GN-S/S3+3GN18K，3IK15GN-S/S3+3GN20K，3IK15GN-S/S3+3GN25K，3IK15GN-S/S3+3GN30K，3IK15GN-S/S3+3GN36K，3IK15GN-S/S3+3GN40K，3IK15GN-S/S3+3GN50K，3IK15GN-S/S3+3GN60K，3IK15GN-S/S3+3GN75K，3IK15GN-S/S3+3GN75K，3IK15GN-S/S3+3GN100K，3IK15GN-S/S3+3GN120K，3IK15GN-S/S3+3GN150K，3IK15GN-S/S3+3GN180K，3IK15GN-S/S3+3GN200K，3IK15GN-S/S3+3GN250K
6W三相220V刹车减速电机型号汇总：
3IK15GN-SM+3GN3K，3IK15GN-SM+3GN5K，3IK15GN-SM+3GN7.5K，3IK15GN-SM+3GN9K，3IK15GN-SM+3GN10K，3IK15GN-SM+3GN12.5K，3IK15GN-SM+3GN15K，3IK15GN-SM+3GN18K，3IK15GN-SM+3GN20K，3IK15GN-SM+3GN25K，3IK15GN-SM+3GN30K，3IK15GN-SM+3GN36K，3IK15GN-SM+3GN40K，3IK15GN-SM+3GN50K，3IK15GN-SM+3GN60K，3IK15GN-SM+3GN75K，3IK15GN-SM+3GN90K，3IK15GN-SM+3GN100K，3IK15GN-SM+3GN120K，3IK15GN-SM+3GN150K，3IK15GN-SM+3GN180K，3IK15GN-SM+3GN200K，3IK15GN-SM+3GN250K
6W三相380V刹车减速电机型号汇总：
3IK15GN-S3M+3GN3K，3IK15GN-S3M+3GN5K，3IK15GN-S3M+3GN7.5K，3IK15GN-S3M+3GN9K，3IK15GN-S3M+3GN10K，3IK15GN-S3M+3GN12.5K，3IK15GN-S3M+3GN15K，3IK15GN-S3M+3GN18K，3IK15GN-S3M+3GN20K，3IK15GN-S3M+3GN25K，3IK15GN-S3M+3GN30K，3IK15GN-S3M+3GN36K，3IK15GN-S3M+3GN40K，3IK15GN-S3M+3GN50K，3IK15GN-S3M+3GN60K，3IK15GN-S3M+3GN75K，3IK15GN-S3M+3GN90K，3IK15GN-S3M+3GN100K，3IK15GN-S3M+3GN120K，3IK15GN-S3M+3GN150K，3IK15GN-S3M+3GN180K，3IK15GN-S3M+3GN200K，3IK15GN-S3M+3GN250K
6W三相通用220V/380V刹车减速电机型号汇总：
3IK15GN-YM+3GN3K，3IK15GN-YM+3GN5K，3IK15GN-YM+3GN7.5K，3IK15GN-YM+3GN9K，3IK15GN-YM+3GN10K，3IK15GN-YM+3GN12.5K，3IK15GN-YM+3GN15K，3IK15GN-YM+3GN18K，3IK15GN-YM+3GN20K，3IK15GN-YM+3GN25K，3IK15GN-YM+3GN30K，3IK15GN-YM+3GN36K，3IK15GN-YM+3GN40K，3IK15GN-YM+3GN50K，3IK15GN-YM+3GN60K，3IK15GN-YM+3GN75K，3IK15GN-YM+3GN90K，3IK15GN-YM+3GN100K，3IK15GN-YM+3GN120K，3IK15GN-YM+3GN150K，3IK15GN-YM+3GN180K，3IK15GN-YM+3GN200K，3IK15GN-YM+3GN250K
6W三相通用220V/380V刹车减速电机型号汇总：
3IK15GN-S/S3M+3GN3K，3IK15GN-S/S3M+3GN5K，3IK15GN-S/S3M+3GN7.5K，
3IK15GN-S/S3M+3GN9K，3IK15GN-S/S3M+3GN10K，3IK15GN-S/S3M+3GN12.5K，3IK15GN-S/S3M+3GN15K，3IK15GN-S/S3M+3GN18K，3IK15GN-S/S3M+3GN20K，3IK15GN-S/S3M+3GN25K，3IK15GN-S/S3M+3GN30K，3IK15GN-S/S3M+3GN36K，3IK15GN-S/S3M+3GN40K，3IK15GN-S/S3M+3GN50K，3IK15GN-S/S3M+3GN60K，3IK15GN-S/S3M+3GN75K，3IK15GN-S/S3M+3GN90K，3IK15GN-S/S3M+3GN100K，3IK15GN-S/S3M+3GN120K，3IK15GN-S/S3M+3GN150K，3IK15GN-S/S3M+3GN180K，3IK15GN-S/S3M+3GN200K，3IK15GN-S/S3M+3GN250K
